CERTIFICATION : CQC/CE/RoHS
MATERIAL
Size(mm) : 8.2x57.7x42.2
Clamping : Spring Stainless Steel
Conductor : Tin-Coated Copper
Housing : PA66/V-0
ELECTRICAL DATA
Impulse Voltage : (kV) 8
Standards : IEC 60947-7-2 UL 1059
Voltage(V) : -
Current(A) : -
WIRING DATA
Strip Length(mm) : 10~12
Metric Wire(mm²) : 0.5~6
Imperial Wire(AWG) :20~8
Connection Points : 2
