250 V DC conforming to IEC 60947-2 440 V AC 50/60 Hz conforming to IEC 60947-2
Breaking capacity code
N
Breaking capacity
36 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 40 kA Icu at 220/230 V AC 50/60 Hz conforming to IEC 60947-2 36 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-2 36 kA Icu at 400/415 V AC 50/60 Hz conforming to IEC 60947-2
[Ics] rated service breaking capacity
18 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 20 kA at 220/230 V AC 50/60 Hz conforming to IEC 60947-2 18 kA at 380 V AC 50/60 Hz conforming to IEC 60947-2 18 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-2
Suitability for isolation
Yes conforming to IEC 60947-2
utilisation category
Category A
Trip unit name
TM-D
Trip unit technology
Thermal-magnetic
Trip unit rating
350 A at 50 °C
Protection type
Short-circuit protection Overload protection
Pollution degree
3 conforming to IEC 60947
Complementary
control type
Toggle
Mounting mode
Fixed
mounting support
Backplate
Upside connection
Front
downside connection
Front
Mechanical durability
10000 cycles
Electrical durability
Category A: 4000 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2
Connection pitch
45 mm
Local signalling
Positive contact indication
Contact position indicator
Yes
Magnetic tripping current
3200 A
Neutral protection setting
Without protection
Long time pick-up adjustment type Ir
Fixed
Long time delay adjustment type
Fixed
earth-leakage protection
Without
height
255 mm
Width
185 mm
Depth
140 mm
Net weight
6.4 kg
