Catridge Schneider TMC2AQ2V 2 Analog Current Outputs

Roll over image to zoom in

Catridge Schneider TMC2AQ2V 2 Analog Current Outputs

Name: Catridge Schneider TMC2AQ2V 2 Analog Current Outputs
Brand: Schneider
SKU: 0012443
Price: 1216100.0 IDR
Availability: OutOfStock

SchneiderSKU: 0012443

filler

Share this product

Range of product	Modicon M221
Product or component type	Analogue output cartridge
Product compatibility	Modicon M221C

Complementary
analogue output number	2
Analogue output type	Voltage: 0...10 V
Analogue output resolution	12 bits
LSB value	2.44 mV 0...10 V voltage
Load type	Resistive
Load impedance ohmic	>= 2 kOhm
Conversion time	20 ms
Stabilisation time	40 ms
Absolute accuracy error	+/- 1 % of full scale +/- 0.3 % of full scale at 25 °C
Temperature drift	+/- 0.02 %FS/°C
Repeat accuracy	+/- 0.4 %FS
Non-linearity	+/- 0.01 %FS
Cross talk	<= 1 LSB
Type of cable	Twisted shielded pairs cable
Electrical connection	3 x 1.5 mm² 2 screw terminal blocks with pitch 3.81 mm adjustment for outputs
Maximum cable distance between devices	Twisted shielded pairs cable: <30 m for output
Insulation	Non-insulated between analogue output and internal logic
height	41 mm
Depth	15 mm
Width	35 mm
Net weight	0.015 kg

Environment
Immunity to microbreaks	10 ms
