20…100 Hz 25…277 V AC phase to neutral 20…100 Hz 44…480 V AC phase to phase
Accuracy
Frequency +/- 0.2 % of full scale
Device mounting
Flush
mounting support
Panel
Type of installation
Indoor
Measurement category
Category III
standards
IEC 61326
Product certifications
CE conforming to IEC 61010-1
Environment
Electromagnetic compatibility
Conducted and radiated emissions class A conforming to CISPR 11 Electrostatic discharge conforming to IEC 61000-4-2 Electrical fast transient/burst immunity test conforming to IEC 61000-4-4 Surge immunity test conforming to IEC 61000-4-5 Conducted RF disturbances conforming to IEC 61000-4-6 Magnetic field at power frequency conforming to IEC 61000-4-8 Voltage dips and interruptions immunity test conforming to IEC 61000-4-11 Harmonics conforming to IEC 61000-3-2 Limitation of voltage changes, voltage fluctuations and flicker in low-voltage conforming to IEC 61000-3-3
IP degree of protection
Front panel: IP50 Body: IP30
Relative humidity
5…95 %
Pollution degree
2
Ambient air temperature for operation
-10…60 °C
Ambient air temperature for storage
-25…70 °C
Colour
Black
Width
96 mm
height
96 mm
Depth
38 mm
Cut-out dimensions
92 x 92 mm
Net weight
160 g
