40 mA at 5 V DC via bus connector (at state on) 5 mA at 5 V DC via bus connector (at state off) 0 mA at 24 V DC via bus connector (at state on) 0 mA at 24 V DC via bus connector (at state off)
Discrete input voltage type
DC
Voltage state 1 guaranteed
15...28.8 V for input
Current state 1 guaranteed
>= 2.5 mA (input)
Voltage state 0 guaranteed
0...5 V for input
Current state 0 guaranteed
<= 1 mA (input)
Input impedance
3.4 kOhm
Response time
4 ms (turn-on) 4 ms (turn-off)
Local signalling
1 LED per channel (green) for input status
Electrical connection
10 x 1.5 mm² removable screw terminal block with pitch 3.81 mm adjustment for inputs
Maximum cable distance between devices
Unshielded cable: <50 m for regular input
Insulation
Between input and internal logic at 500 V AC Non-insulated between inputs
Marking
CE
Mounting support
Top hat type TH35-15 rail conforming to IEC 60715 Top hat type TH35-7.5 rail conforming to IEC 60715 plate or panel with fixing kit
Height
90 mm
Depth
84.6 mm
Width
27.4 mm
Net weight
0.1 kg
Environment
Standards
IEC 61131-2
Product certifications
CE cULus UKCA RCM EAC cULus HazLoc
