6 kV between coil and contact with reinforced insulation 4 kV between contacts with basic insulation 4 kV between poles with basic insulation 4 kV between terminals and DIN rail with basic insulation
[In] rated current
5 A
[Ue] rated operational voltage
250 V conforming to IEC 300 V conforming to UL
Dielectric strength
5 kV between coil and contact with reinforced insulation 2.5 kV between contacts with basic insulation 3 kV between poles with basic insulation 3 kV between terminals and DIN rail with basic insulation
Connections - terminals
Screw terminals, 1 x 0.25...1 x 2.5 mm² (AWG 22...AWG 14) flexible with cable end Screw terminals, 2 x 0.25...2 x 1 mm² (AWG 22...AWG 17) flexible with cable end Screw terminals, 2 x 0.5...2 x 1.5 mm² (AWG 20...AWG 16) solid without cable end Screw terminals, 1 x 0.5...1 x 2.5 mm² (AWG 20...AWG 14) solid without cable end
Screw type
M3
Environment
Ambient air temperature for storage
-40…85 °C
Ambient air temperature for operation
-40…70 °C
Relative humidity
10…85 %
standards
CSA C22.2 No 14 IEC 61984 UL 508
product certifications
EAC CE CSA UL DNV-GL
