Description
| Metode tampilan | LED 4 digit 7-segmen |
|---|---|
| Metode operasi | Counter: Count up, Count down, Count up/down Timer: Count up, Count down |
| Terminal | Terminal block |
| Operasi output | SIGNAL ON DELAY, POWER ON DELAY, FLICKER, INTERVAL, SIGNAL OFF DELAY, ON-OFF DELAY, INTEGRATION TIME |
| Catu daya | 24VAC~ 50/60Hz, 24-48VDC
|
| Waktu operasi | POWER ON START SIGNAL ON START |
| Catu daya eksternal | Maks. 12VDC ±10%, 100mA |
| Metode sinyal input | Input tegangan (PNP), tanpa input tegangan (NPN) |
| Maks. Kecepatan counting | 1, 30, 1k, 5k, 10k [cps] |
| Min. lebar sinyal | 1ms/20ms |
| Proteksi memori | kurang lebih 10 tahun |
| Kisaran pengaturan | 01 sec to 9.999 sec, 0.01 sec to 99.99 sec, 0.1 sec to 999.9 sec, 1 sec to 9999 sec, 1 sec to 99 min 59 sec, 0.1 min to 999.9 min, 1 min to 9999 min, 1 min to 99 hour 59 min, 1 hour to 9999 hour |
| Output kontrol_tipe | 1-stage preset |
| Output kontrol_relai | SPDT (1c): 1 |
| Output kontrol_NPN open collector | 1 |
| Tingkat proteksi | IP65(panel depan) |
| Sertifikasi |

|
| Counter_Kisaran counting | -999 ~ 9999 |
| Counter_skala | Titik desimal sampai 5 digit |
| Counter_Min. lebar sinyal input | RESET: Pilihan 1ms/20ms |
| Timer_Min. lebar sinyal input | INA, INH, RESET: Pilihan 1ms/20ms |
| Lingkungan_kadar suhu | -10 hingga 55℃, ruang tertutup: -25 hingga 65℃ |
| Lingkungan_kadar kelembaban | 35 ~ 85%RH, ruang tertutup: 35 ~ 85%RH |
| Berat | Kurang lebih 212g (kurang lebih 159g) |
