Outlet RJ45 CAT 5 AvatarOn E8331RJS5_DG Black

Name: Outlet RJ45 CAT 5 AvatarOn E8331RJS5_DG Black
Brand: Schneider
SKU: 0016627
Price: 138500.0 IDR
Availability: OutOfStock

Save 14%

SchneiderSKU: 0016627

Share this product

Main
Product or component type	Data socket
Device application	Communication
Socket additional information	Shuttered
Communication network category	Data: 5e
Number of gangs	1 gang
Colour tint	Wine gold
Main colour tint	Wine gold

Complementary
Device presentation	Complete product
Device mounting	Flush Surface
Data socket type	RJ45
Rated current	1.5 A
Material	Polycarbonate: plastic part
Contacts material	Housing: PC Contact: phosphor bronze with gold plating
Contact resistance	1 µOhm
Insulation resistance	>= 200 MOhm
Minimum return loss	23 dB
Colour tint	Wine gold
IP degree of protection	IP20
Width	86 mm
height	86 mm
Depth	31 mm

Environment
Dielectric strength	1000 V for 60 s at 60 Hz
AWG gauge	AWG 26...AWG 22 (4 twisted pair cables)
Environmental characteristic	No UV resistant
Maximum ambient air temperature for operation	35 °C
Relative humidity	0…95 %
standards	TIA/EIA-568-B.2-1 ASTMD4566-98
