SPESIFIKASI PRODUK
-
Brand: OMRON
-
Model: E2B-S08KN04-WP-C1 2M
-
Type: Inductive Proximity Sensor / Proximity Switch
-
Series: E2B
-
Size: M8
-
Mounting Type: Non-flush / Unshielded
-
Sensing Distance: 4 mm ±10%
-
Setting Distance: 0–3,2 mm
-
Standard Sensing Object: Mild Steel ST37, 12 × 12 × 1 mm
-
Power Supply: 10–30VDC
-
Current Consumption: Max. 10 mA
-
Output: NPN Open Collector
-
Operation Mode: NO (Normally Open)
-
Load Current: Max. 200 mA
-
Response Frequency: Max. 1.000 Hz
-
Indicator: Yellow LED
-
Connection: Pre-wired
-
Housing: Stainless Steel
-
Sensing Surface: PBT
-
Degree of Protection: IP67
-
Operating Temperature: -25°C sampai +70°C
-
Operating Humidity: 35–95% RH
-
Overall Length: ±42 mm
-
Thread Length: ±21 mm
KEUNGGULAN
✓ Brand Omron Terpercaya
✓ Ukuran compact M8
✓ Sensing distance 4 mm
✓ Output NPN Normally Open (NO)
✓ Supply 10–30VDC
✓ 3-wire sehingga mudah diintegrasikan dengan rangkaian kontrol
✓ Kabel pre-wired 2 meter
✓ Housing stainless steel
✓ Proteksi IP67 terhadap debu dan air
✓ Dilengkapi LED indicator
✓ Cocok untuk mesin dan sistem otomasi industri
BERAT PRODUK
Perkiraan ±65 gram/unit
