FEED-THROUGH TERMINAL WT 16 BL Wieland 58.516.0055.6

WielandSKU: 0011525

Share this product

Nominal cross section	16 mm²
Color	Blue
Number of levels	1
Number of clamp positions per level	2
Width/grid dimension	12 mm
Insulating housing	PA666
Inflammability class of insulation material acc. with UL94	V0
Mounting method	DIN rail (top hat rail)
Terminal blocks for electrical installations	yes

Technical data

Connection Data

Connection type 1	screw connection
Connection type 2	screw connection
Minimum cross section solid	1.5 mm²
Maximum cross section solid	16 mm²
Minimum cross section fine stranded	4 mm²
Maximum cross section fine stranded	25 mm²
Minimum cross section stranded	16 mm²
Maximum cross section stranded	25 mm²
Minumum conductor cross section (flex., stranded) with cable end sleeve	1.5 mm²
Maximum conductor cross section (flex., stranded) with cable end sleeve	16 mm²
Wire strip length	15 mm
Torque conductor mounting	2 Nm

Technical Data UL/CSA

Classification

Product compliance

REACH-SVHC conformity status	Compliant
