60 mA, 60 mA, 600.0 mA, 60 A, 60 A, 200.0 A, 6 ranges, True RMS Basic accuracy 45 Hz - 400 Hz: ±1.0% rdg ±5 dgt (60 mA to 60 A), ±1.5% rdg ±5 dgt (60 A, 200.0 A) Basic accuracy 15 Hz - 45 Hz, 400 Hz - 2 kHz: ±2.0% rdg ±5 dgt Defined accuracy range: 0.060 mA to 200.0 A
AC Voltage range
N/A
Frequency range
15.0 Hz to 2000 Hz
Crest factor
3 (other than 200.0 A range), 1.5 (200.0 A range)
Filter function
Cut off frequency: 180 Hz ±30 Hz at filter ON (-3 dB)
Output function
RMS (RMS value output), WAVE (waveform output)
Harmonic levels
[With Z3210 installed] Current harmonic levels up to 30th, Content factor, Total harmonic distortion ratio *Harmonics can be displayed with our free app GENNECT Cross.
Other functions
Max/ Min/ AVG/ PEAK MAX/ PEAK MIN value display, Display value hold and auto hold; Backlight, Auto power save, Buzzer sound, Event count display, Comparator, Simple event recording, Rush current measurement
Display
Display refresh rate: 5 times/s
Power supply
- AA-size alkaline battery (LR6) × 2; Continuous operating time: 48 hr. (without Z3210 installed), 30 hr. (with Z3210 installed and using wireless communications) - AC Adapter Z1013 (5 V DC, 2.6 A)
Core jaw diameter
φ 40 mm (1.57 in.)
Dimensions and mass
64 mm (2.52 in) W × 233 mm (9.17 in) H × 37 mm (1.46 in) D, 400 g (14.1 oz.)
