SPESIFIKASI PRODUK
-
Brand: OMRON
-
Model: TL-W3MC1
-
Series: TL-W
-
Type: Flat Inductive Proximity Sensor
-
Sensor Type: Inductive
-
Connection: DC 3-Wire
-
Output: NPN Open Collector
-
Operation Mode: NO (Normally Open)
-
Sensing Distance: 3 mm ±10%
-
Setting Distance: 0–2,4 mm
-
Detectable Object: Ferrous Metal
-
Standard Sensing Object: Iron 12 × 12 × 1 mm
-
Response Frequency: 600 Hz min.
-
Rated Voltage: 12–24VDC
-
Operating Voltage: 10–30VDC
-
Ripple: Maks. 20% p-p
-
Current Consumption: Maks. 10mA pada 24VDC tanpa beban
-
Output Load Current: Maks. 100mA pada 30VDC
-
Residual Voltage: Maks. 1V
-
Indicator: Detection Indicator (Red)
-
Protection: Reverse Polarity Protection & Surge Suppressor
-
Operating Temperature: -25°C hingga +70°C
-
Operating Humidity: 35–95% RH
-
Protection Degree: IP67
-
Connection Method: Pre-wired
-
Cable Length: 2 meter
KEUNGGULAN
✓ Brand Omron Terpercaya
✓ Sensing distance 3 mm
✓ Supply 12–24VDC
✓ Operating range 10–30VDC
✓ Output NPN Open Collector
✓ Konfigurasi 3 Wire
✓ Mode NO (Normally Open)
✓ Bentuk Flat yang praktis untuk area dengan ruang terbatas
✓ Kabel pre-wired 2 meter
✓ Protection IP67
✓ Response frequency hingga 600 Hz
BERAT PRODUK
Perkiraan ±80 gram/unit
