RCBO Slim Domae DOMD01610 1P+N 10A 30mA Schneider

Name: RCBO Slim Domae DOMD01610 1P+N 10A 30mA Schneider
Brand: SCHNEIDER
SKU: 0010532
Price: 419000.0 IDR
Availability: InStock

★★★★★(35)

167 Terjual

Save 14%

SCHNEIDERSKU: 0010532

Share this product

Main
range	Domae
device application	Distribution
product name	AD63 K
product or component type	Residual current breaker with overcurrent protection (RCBO)
poles description	1P + N
neutral position	Left
earth-leakage protection class	Type AC
suitability for isolation	Yes

Complementary
[In] rated current	10 A at 30 °C
network type	AC
network frequency	50 Hz
[Ue] rated operational voltage	230/240 V AC 50 Hz
trip unit technology	Thermal-magnetic
curve code	C
magnetic tripping limit	5...10 x In
earth-leakage sensitivity	30 mA
earth-leakage protection time delay	Instantaneous
breaking capacity	4500 A Icn at 230/240 V AC 50 Hz
electrical insulation class	Class II
limitation class	3
[Ui] rated insulation voltage	400 V AC 50 Hz
contact position indicator	Yes
control type	Toggle
local signalling	ON/OFF indication
mounting support	DIN rail
comb busbar and distribution block compatibility	YES
9 mm pitches	2
height	93 mm
width	18 mm
depth	70 mm
net weight	136 g
colour	Grey
mechanical durability	20000 cycles
provision for padlocking	Padlockable
locking options description	By padlocks
connections - terminals	Screw clamp terminal (upstream) 1…16 mm² rigid Screw clamp terminal (upstream) 1…16 mm² flexible Screw clamp terminal (downstream) 1…10 mm² rigid Screw clamp terminal (downstream) 1…10 mm² flexible
wire stripping length	14 mm for upstream connection 11 mm for downstream connection
tightening torque	2 N.m upstream 2 N.m downstream
earth-leakage protection	Integrated

Environment
standards	IEC 61009-1 IEC 61009-2-2
product certifications	SNI
ambient air temperature for operation	-25…55 °C
ambient air temperature for storage	-30…70 °C
