3 A (AC-1/DC-1) NO conforming to IEC 1.5 A (AC-1/DC-1) NC conforming to IEC
Minimum switching current
10 mA
Maximum switching voltage
250 V AC 28 V DC
Minimum switching voltage
17 V
Load current
3 A at 250 V AC 3 A at 28 V DC
Maximum switching capacity
750 VA AC 84 W DC
Minimum switching capacity
170 mW
Operating rate
<= 1200 cycles/hour under load <= 18000 cycles/hour no-load
Mechanical durability
10000000 cycles
Electrical durability
100000 cycles for resistive load
Average coil consumption in VA
1.2 AC
Drop-out voltage threshold
>= 0.15 Uc AC
Operating time
20 ms between coil de-energisation and making of the Off-delay contact 20 ms between coil energisation and making of the On-delay contact
Average resistance
180 Ohm at 23 °C +/- 10 %
Rated operational voltage limits
19.2...26.4 V AC
Protection category
RT I
Test levels
Level A group mounting
Operating position
Any position
CAD overall width
21 mm
CAD overall height
27 mm
CAD overall depth
46 mm
Net weight
0.035 kg
Dielectric strength
2000 V AC between coil and contact with basic insulation 2000 V AC between poles with basic insulation 1000 V AC between contacts with micro disconnection
Safety reliability data
B10d = 100000
Environment
Standards
EN/IEC 61810-1 (iss. 2) CE
